Continuous Operation: Designed for continuous waste processing with an integrated automated system.
Adjustable Temperature: Features a 600-900℃ adjustable temperature control for versatile waste handling.
Safety Design: Utilizes a negative pressure design to prevent backfire during operation.
Advanced Filtration: Incorporates a multi-stage exhaust treatment system including a cyclone dust collector.
Automated Workflow: Integrates feeding, screening, drying, incineration, ash removal, and dust removal.
Feature | Advantage | Buyer Benefit |
|---|---|---|
Negative pressure design | Prevents backfire during the combustion process. | Enhances operator safety and prevents accidental equipment damage. |
600-900℃ adjustable incineration temperature | Ensures complete combustion of various waste types while protecting the furnace from thermal shock during shutdown via an automated cooling program. | Increases equipment lifespan and provides reliable, customizable waste reduction. |
Multi-stage exhaust treatment | Effectively filters and processes smoke and exhaust gases before emission using high temperature, jet vortex combustion, secondary combustion, and a cyclone dust collector. | Reduces environmental impact and aids in achieving harmless waste processing goals. |
Fully integrated automated system | Reduces manual labor and handles the entire waste treatment cycle (feeding, screening, drying, incinerating, ash/dust removal) in continuous operation. | Lowers daily operational costs and simplifies waste management for operators. |
Incineration Temperature | 600-900℃ (Adjustable control) |
Design Average Calorific Value | 2500 Kcal/Kg |
Waste Gas Treatment | High temperature + high-temperature jet vortex combustion + secondary combustion + cyclone dust collector + chimney |
System Composition | Waste pre-treatment system, incineration system, biochemical dust removal system, and gas generator (auxiliary ignition) |
Ignition Type | Automatic ignition using diesel fuel |
Safety Features | Electrical leakage protection (insulation resistance ≥24MΩ at 85% relative humidity); Pre-installed and pressure-tested oil and gas circuits |
Footprint & Installation | Small footprint, utilizes a simple rainproof shed |
Suitable for solid waste treatment facilities.
Designed for industrial waste treatment and continuous disposal operations.
Processing Capacity: Please confirm your required daily processing capacity (e.g., kg/day or tons/day) prior to ordering.
Dimensions & Space: Exact physical dimensions (L x W x H) and equipment weight can be provided based on specific configuration requirements.
Power Requirements: Specific electrical power supply voltage and total power consumption details should be verified during inquiry.
Compliance & Standards: Depending on application requirements, please confirm local environmental emission standards to ensure appropriate exhaust treatment configuration.
Warranty: Details regarding the standard warranty period and coverage can be confirmed during the quotation process.
Q: What is the operating temperature range of the incinerator?
A: The incinerator features an adjustable temperature control ranging from 600℃ to 900℃, allowing it to handle different types of solid waste effectively.
Q: How does the equipment handle exhaust gases?
A: It utilizes a multi-stage waste gas treatment system that includes high-temperature processing, jet vortex combustion, secondary combustion, a cyclone dust collector, and a chimney.
Q: Is the system safe from backfire during operation?
A: Yes, the incinerator is engineered with a negative pressure design specifically to prevent backfire and enhance operational safety.
Q: Does the machine require manual feeding and ash removal?
A: No, the system integrates automatic feeding, screening, drying, incineration, ash removal, and dust removal for continuous, automated operation.
To receive a detailed quotation, please submit your specific application requirements, including your target daily processing capacity, local emission compliance standards, and available installation space. Our team will provide equipment specifications tailored to your waste treatment needs.
